WS2812B Pixel LED Strip Addressable LED rigid strip 74 leds 5V

74 led each meter, The unit price is each meter. WS2812B LED Strip Individual Addressable Light SMD5050 RGB Strip Full Color LED Pixel Strip DC5V, WS2812B LED flexible strip, WS2812B LED rigid strip. You can buy our Addressable LED strip controller to control this RGB Pixel LED Strip.

WS2812B is a intelligent control LED light source that the control circuit and RGB chip are integrated in a package of 5050 components. It internal include intelligent digital port data latch and signal reshaping amplification drive circuit. Also include a precision internal oscillator and a 5V voltage programmable constant current control part, effectively ensuring the pixel point light color height consistent.

The data transfer protocol use single NZR communication mode. After the pixel power-on reset, the DIN port receive data from controller, the first pixel collect initial 24bit data then sent to the internal data latch, the other data which reshaping by the internal signal reshaping amplification circuit sent to the next cascade pixel through the DO port. After transmission for each pixel?the signal to reduce 24bit. pixel adopt auto reshaping transmit technology, making the pixel cascade number is not limited the signal transmission, only depend on the speed of signal transmission.

LED with low driving voltage, environmental protection and energy saving, high brightness, scattering angle is large, good consistency, low power, long life and other advantages. The control chip integrated in LED above becoming more simple circuit, small volume, convenient installation.

Features and Benefits
 Intelligent reverse connect protection, the power supply reverse connection does not damage the IC.  The control circuit and the LED share the only power source.  Control circuit and RGB chip are integrated in a package of 5050 components, form a complete control of pixel point.  Built-in signal reshaping circuit, after wave reshaping to the next driver, ensure wave-form distortion not accumulate. ? Built-in electric reset circuit and power lost reset circuit. ? Each pixel of the three primary color can achieve 256 brightness display, completed 16777216 color full color display, and scan frequency not less than 400Hz/s.  Cascading port transmission signal by single line.  Any two point the distance more than 5m transmission signal without any increase circuit.  When the refresh rate is 30fps, cascade number are not less than1024 points.  Send data at speeds of 800Kbps.  The color of the light were highly consistent, cost-effective.

Applications
LED flexible strip,LED rigid strip,Full color led module.
LED decorative lighting, Indoor/outdoor LED video irregular screen.

Dream full color Programmable LED Strip,WS2812B led, WS2812B IC Built in 5050SMD.256 brightness display and 24-bit color display.It comes with 3pin JST-SM connectors on both ends for easy installation and separated power/ground wires on both ends. Each LED can be cut off without damaging the rest strip. You can shorten, lengthen or bend it freely if you want.

Product Description
WS2812b LED strip is a 3-channel addressable strip with built-in IC, controlled by dedicated LED controllers
One LED as one individually addressable pixel, IC is integrated into the LED, not visible on strips
Less components on strips, easier for installation and bend
Working voltage is DC5V, max 5.5V?Min 3.5V

Transmission distance is 5 meters between any 2 pixels
Signal is a serial single-wire cascade interface, which is transmitted through one signal lines
PWM controller can adjust 256 gray levels, totally can output 16,777,216 colors
WS2812b LED strip is a 5V individually addressable strip, the IC is embedded into the 5050 LED, which makes it has a better lighting performance.

The built-in IC is invisible from outside, this makes the strips more robust and more flexible to be applied on different types of surfaces.
As the individually addressable pixel, each LED is cuttable.
It’s the 1st individually addressable light source since few years ago hence it has been widely used in everywhere, maybe the most popular addressable light source so far.
WS2812 is a intelligent control LED light source that the control circuit and RGB chip are integrated in a package of 5050 components.
It has built-in signal reshaping circuit, after wave reshaping to the next driver, ensure wave-form distortion not accumulated.
It runs with low driving voltage, environmental friendly and energy saving, has high brightness, scattering angle is large and good consistency.
The control chip integrated in LED above becoming more simple circuit, small volume, convenient installation.
SDIP supply the WS2812 programmable LED strip in 30LEDs/meter, 60LEDs/meter and 144LEDs/meter, based on different waterproof rate, IP20/IP65/IP67/I68, along with the LED power supply and LED controllers.
Combining with aluminium profile, these flexible strips can be made into rigid LED strip.
Besides the physical LED strips, SDIP also provides the one-stop services of Site audit, Layout design, Lighting effect and programming based on LedEdit or Madrix software platforms, Product development and implementation, installation and debugging, we have the field engineer teams to assist you at your sites.
IC: WS2812B
FPCB Color: White/Black
IC Quantity: 74 IC/meter
Max Power: 22w/m
PCB Width: 10mm
Channel Order: RGB
LED Type:    SMD5050
Gray Scale: 256
LED Quantity: 74 LEDs/meter
IP rate: IP20, IP65, IP67
