60W DC/DC power Supply 12V isolated output for AV, DVR on cars

Input Data:

Input Voltage:

8~36VDC

Input Current

5A @12VDC

Impact Current:

10A

Input Fuse:

10A

Output Data:

Output Voltage:

+12V

Output Current

5A

Voltage Regulation

2%

Output Ripple

100mV

Overvoltage Protection

Yes

Overcurrent Protection

Yes

Short-circuit Protection

Yes

Risetime

10ms

EMC standard

Transmission Standard:

EN55022, Level A

Radiation Standard:

EN55022, Level A

Static Standard:

EN61000-4-2, Level 3

Thunderstrike Standard

EN61000-4-5, Level 2

Eradiation Standard:

EN61000-4-3 10V/m

Surrounding Specifications:

Operating Temperature:

-10 to +50

Storage Temperature:

-40 to +85

Cooling Mode:

Natural cooling

Relative Humidity:

5% to 95% RH

Operating Height:

10,000 Feet max.

Vibration Standard:

5~500Hz, 2.4G rms

General Specifications:

Efficiency:

85% typical

Hold-up Time:

1ms

Switching Frequency:

Fixed 200KHz

Safety Standard:

CE, CCC

Weight:

350g

Size:

103X70X45mm

Average No-Fault Time:

>120,000 hours
