Tuya Smart Switch Remote Push Button RF Wireless Relay receiver

3 Relay+ 2 stickable wall panel ( with 3 switch each panel) Tuya Wifi Switch Smart Light Switch Remote Push Button Switch RF Wireless Relay receiver AC110V 220V,Work with Alexa google home.

Stickable wall panel color option: White, Black, Gold

Smart phone tuya app/Smart Life app control / 433Mhz wall panel control / Alexa voice Control
Working voltage   : AC90~250V
Quiescent Current  :  <5MA
MaxLOAD  :  10A
Load type: Motor, light bulb and all other mains voltage operation equipment
Control mode  :  RF remote control / App control
RF frequency  :  433MHz
Working temperature  :  -30~+80 degree C
Receiving Sensitivity  :  >97dbm
Amount of storage remote controls  :  25 pieces
Support encoding   : 1527 Leaning code/ 2262 fixed code
RF Operating mode  :  ASK superheterodyne wireless reception
Wi-fi  :  IEEE 802.11 b/g/n
Compatibility  :  APP for IOS and Android.
Access intelligent speaker  :  Amazon echo / Google home
Remote operating mode  :  Momentary Mode /Toggle Mode /Latched Mode

RF Operating Mode
Set up
1. Press the learning button(on the Receiver)twice. Wait for 3 seconds;
2. Press one button on the wall switch. Wait for 3 seconds. Succeed.

Reset
Press the learning button (on the Receiver) 8 times. The existing data will be deleted succeed.

Phone App Operating Mode
1. Scan QR code of user guide on the case.
2. iOS, Android user download your APP.
3. Add and connect device according to the user guide and FAQ.

Q & A
Q :Can the receiver be controled by wall switch and phone App?
A :Yes,the receiver be controled by wall switch and phone App at the same time.

Q : Can one receiver be controled by diffrent wall switch?
A : Yes, each receiver can add about 20 wall switch.

Q : Can one wall switch control 2 receivers individually ?
A : Yes, wall switch with 2 buttons can control 2 receivers ,wall switch with 3 buttons can control 3 receivers.

Q : Can 1 button on wall switchcontrol 2 receivers at the same time?
A : Yes , You can program it by yourself. For example, matched Button "1" with receiver "1",and then matched Button "1" with receiver "2" too. This Button "1" can control receiver "1" and receiver "2" at the same time.
